Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 329
306.—Parsons Vacuum Augmenter. capacity. (4) Hurling-water pumps (Figs. 303, 304 and 305),sometimes called hydro-centrifugal pumps. These are used asdry-vacuum pumps chiefly in turbine installations where thevacuum is high and the volume of air to be handled is relatively 308 STEAM POWER PLANT… … Boi/er. ■DischargeOpening? Fig. 306A.—Wheeler Two-Stage Radojet Air Pump Without Inter-condenser.(Air and water vapor are drawn from the condenser in through the suction chamber, E,by steam issuing from the nozzles, D, at a velocity of about 3,000 ft. per sec. Themixture is discharged into the…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
