ft.The coal consumption of the boilers while furnishing steam for this work is 3,500 lb.What is the duty of the pump per 100 lb. of coal? DIVISION 2DIRECT-ACTING STEAM PUMPS 51. Direct-Acting Steam Pumps For Modern Power-PlantService are (Fig. 27) of the reciprocating double-acting,suction type.… … Brass Liner Forced • into Cylinder Under } Pressure Water-Piston ^\\\v\\\\^\\\v\\m\\\\\m Fig. 27.—Water-End Of Direct-Acting Steam-Pump Having Water-Piston Fitted WithSnap Rings. Explanation.—The movement toward the left of the piston (P-Fig.28) as indicated, causes the water in the space B to be…
