Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 97
ctly (Fig. 86) from the reciprocatingmovement of a piston in a steam cylinder but is dependentfor its continuance upon the inertia effect of the rotative move-ment of a crank-shaft and fly-wheel. (2) Crank-action powerpumps in which the reciprocating movement of the pumppiston or plunger is derived… … Fig. 85.—Horizontal Section Of A Double-Acting Duplex Crank-And-Fly-Wheel Pump. Connecting
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
