iety of Civil Engineers, Vol. UV., p. 405. STICKL CONSTRUCTION transmitted to the web by the rivets connecting the flange anglesto the web. The effect of this load on the number of rivets requiredis considered later in the text. When concentrated loads are applied, enough rivets cannot beplaced in… … Fig. 118. Details of Girder Showing Use of Stiffeners Under Concentrated Load stiffeners may be designed as short compression members using aunit stress of 12,000 pounds per square inch. They must be at-tached to the web plate with enough rivets to transmit the load.Generally the bearing value of…
