Steel ships, their construction and maintenance : a manual for shipbuilders, ship superintendents, students, and marine engineers (1901)
Walton, Thomas · London : Charles Griffin & Co. ; Philadelphia : Lippincott · leaf 274
/C Plan showing the Beam fittedinto the Bosom of the Frame, … Fio. 108.—Bulb Angle Beamwith Welded Knee. DeepFraming Plan. Fig. 109.—Bulb Angle Beam with Bracket Knee. and welding to its extremities a piece of plate of the thickness of the beams(see fig. 108), where the welded plate is shown by hatched lines. Whenthe welding is well done, a stronger knee is…
Naval architecture · Ships, Iron and steel
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
