nown as simple ordirect driving and compound or indirect driving. Adirect drive is one in which the driving pulley is mountedon the crankshaft, which latter receives motion directlythe loom is started; the crankshaft transmitting motionto the other parts of the loom. An indirect drive is onein… … Fig. 3. A direct driving motion is illustrated in Figs. 3 and 4,in plan and back elevation respectively. The loose andfast pulleys A and A^ are mounted on the crankshaft C,the loose pulley being kept in position by a collar, and thefast pulley is secured to the shaft by means of a taper key SWITI…
