Tappet and dobby looms : their mechanism and management (1912)
Roberts, Thomas · Manchester [Greater Manchester] : Emmott & Co., Ltd. · leaf 31
sc—i.e., in the direc-tion of A^ When contact is made the motion is con-veyed through the countershaft and the train of wheels,to the picking and the crank shafts. Features and Advantages of this IndirectDriving Motion.—This type of driving motion possessesseveral noticeable features: (i) A ready… … of the nuts P^ The spring vS serves as an escape motionfor any discrepancy that may be due to error in settingthe movement of the pulley. (2) The bevel wheel D isa change wheel, and is usually supplied with the loom in FEATURES OF INDIRECT DRIVING 21 three sizes. The substitution of one or other of…
