Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics (1889)
Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 212
Fig. 878(5. … Fig. 878a. Fig. 879. roller, one being a left-hand screw and the other a right-hand screw, on a horizontal shaft, E,which has its bearings in brackets XX, also secured to the side of the frame A. One end ofthis shaft ^ is provided with a beveled gear-wheel, which engages with a similar beveled…
Textile fabrics
