Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing (1890)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, S. Low, Marston · leaf 231

An illustration from Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing, 1890, leaf 231
Fig. 899. Fig. 900. forward position for the production of a plain fabric. (Letters indicating the different parts forreference are selected to correspond in all four diagrams.) The method of operation of the loom thus forming the terry pile is as follows :The crank-shaft A when revolving drives to…

Textile fabrics
