l, and from D to intersect W. Xy and erect the per-pendiculars as shewn by the dotted lines. 3rd. From JVand JV, draw lines to define the bot-tom shadow, and at L draw a line at the same angleto touch the curve. 4th. At the same angle draw F. G, make F. H equalto the depth of the panel, and F. G…
