atpresent used in heat motors employing vapors as workingsubstances is the Rankine cycle, illustrated in Fig. 57.During this cycle the heat is received and rejected by thesubstance while it is under constant pressure. This cyclefurther differs from the Carnot cycle in so far that the con-densation… … Fig. 57. I 2, then vaporized in part, or wholly, or even possiblysuperheated, all under the highest constant pressure inthe cycle, process 2 3, then expanded under reversiblyadiabatic conditions 3 4, and finally cooled and condensedto the liquid state under the lowest pressure existing inthe cycle.…
