nd unscrew itto lessen same. Then lock by means of the nut. If the springinside should get coated with salt deposit, remove the wholefitting from the drum and soak it in hot water; clean the seatof the valve and replace. §13 CAR HEATING. 75 FILLER COCK, 89. The special filler cock is shown in… … Fig. 33. heater; c is the main cock, and d and e two draw-off cocks.The figure shows the device in its usual position—open. To blow out obstructions in the heater pipes, close the cock cand open d and e. Connect steam with d and leave e openuntil everything is thoroughly blown out. To fill the…
