Textile design and colour; elementary weaves and figured fabrics (1921)
Watson, William, F.T.I · London, New York [etc.] Longmans, Green and co. · leaf 229
small square ofa horizontal space; and each small square also indicates where an end and a pickintersect. A card is perforated and left blank in the order indicated by the paintingof the design ; if certain marks, or the blanks, represent warp up, a hole is cut tocorrespond with each small square… … Fig. 248. ORDINARY HARNESS TIES 215 at one side the long rows of hooks are at right angles to the length of the comber-board, therefore the harness cords are crossed with each other in passing from theneck-cords to the holes in the comber-board. This arrangement, which is illustratedin Fig. 248, is…
Textile design
