The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 72
ne, one mechanical principle, orset of principles, to which every kind of carder must conform. Taking the general mechanical structure of the carding engine(fig. 60) first, we note that the main tool is a large cylinder placedin the middle of the machine. Over the cylinder, generally namedthe… … Fig. 60.—Old Form of Carding Engine A, Feed lap roller. B, Fluted feed rollers, c, Licker-in. D, Main cylinder. E, E, Workers. F, Stripper.G, Doffer. H, Doffing knife. I, Sliver-forming apparatus. J, Sliver can. K, Carding flat. touch with the swift, is a smaller cylinder named the doffer,…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
