Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)

Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 325

An illustration from Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools, 1901, leaf 325
196.—Nortons Wool-drying Machine (vertical section). With friction gear (Figs. 197 and 198) the fast pulley, a,driven by the shafting, transmits motion through the cog-wheels, c, d, to the shaft, e, on which is mounted the slidingfriction pulley, /. The latter can be adjusted by the hand-wheel, g,… … ^pr^gmf^m^j^nnf^HiSf n^aVBi^i^^^i^^^^^safWf^fifZ ^RE!B«ffP Fig. 197.—Friction-driving Gear ot Nortons Drier (vertical section). ^JH m

Textile fibers · Spinning

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
