The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 146
drum. E, Scroll of drum. F, Quad-rant. G, Governor. H, Quadrant scroll. I, Chain. j. Shaping screw of copping motion. K, Slidingbracket at end of chain. L, Swing lever, m, Bracket on arm of quadrant. ment of the quadrant, after the slack has been taken up, acting throughthe mechanisms we have just… … Fig. 160.—Patent Nosing Motion Finishing Cops A, Carriage. B, Whorl of spindle, c, Finished cop. D, Winding-on drum, e, Scroll of drum. F, Quad-rant. G, Governor. H, Quadrant scroll. i. Chain. J, Shaping screw of copping motion. K, Slidingbracket at end of chain. L, Swing lever. M, Bracket on arm…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
