The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 220
ted together and standing on four feet, this structure was solidly THE POWER LOOM ^n built. Into the side frames were bushed all the driving shafts andcross beams. Tie beams held the side frames in the middle and anarched beam connected them over the top. Having- to stand severevibrations, the… … Fig. 253.—Sharp and Robertss Power Loom: Front Elevation A, A, Frame, b, Wheel on main shaft driving c on the tappet or wiper shaft D. E, Batten. F, F, Swordsof the lay. G, Reed, h, Heddle. i, Breast beam, j, Cloth beam. K, K, Tappets. L, L, Treadle levers.M, One of the peg arms. N, N, Shuttle…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
