The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 96
cop-ping machine. Beingplaced on the frame,the thread is drawnfrom the bobbin andpassed through aconical cap fixed uponthe extremity of anoscillating lever. The thread is attached to the winding spindle, and the oscillating cap,which is a hollow cone, traverses the thread in the winding so as… … Fig. 206.—Cop Machine, to wind from Bobbins {Urquhart, Lindsay & Co.) A, Bobbins. B, Bobbin drag, c. Stoneware whorl carried on a tension wire.D, Thread guide. E, Cop. F, Bevel wheel driving the spindle G. H, Chilledcones. J, Starting pedal. K, Guard. L, Spring for knock-off. m, Clutchlever. N,…
