The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 90
ch the end of a bracketfirmly bolted on the loom frame inserts itself. At the other end of thesmall shaft a collar carrying a crank pin is fitted. From the end ofthe card cylinder comes out a star wheel, bearing against the collaron the shaft, and turned by the crank pin catching into the… … —Independent Cylinder Jacquard A, Connecting rod of eccentric cam. B, Cranked lever, c. Sliding rod carrying the cylinder D, the star-wheelE, and the bearings ff of a rod G which drives the bevel-wheel H. j is a bracket carrying a finger fitting a ring-groove on H, preventing it from slidmg with…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
