The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)

Murphy, William S · London : The Gresham Publishing Company · leaf 72

An illustration from The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing, 1910, leaf 72
Fig. 5ig.—Hinckleys Single-needle Knitter reciprocating motion tolooper carrier j andlooper M, by means ofstud F; G, tumbleroperating reversing finson wheel c; h, rack;I, comb; k, arm carry-ing looper; p, plateattached by bent armp (fig. 519) to base ofmachine, and providedwith spring plate o… … Fig. 520.—Hinckleys Single-needle Knitter: Section showing principal parts Y and the comb i play; Q, rod attached underneath comb i, whichserves to keep the stitches or loops of fabric on the teeth of the comb;s, stud for sleeve of needle carrier t; l, needle guide on looper carrier j;w, tension…

Textile industry · Textile fabrics

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
