Taggart, William Scott · London : George Routledge & Sons, Ltd. · leaf 60
drums arc therefore made so that the rope is wound on atthe start and finish on small diameters, and the diametersgradually increased so that the highest speed of travel takesplace when the carriage is about the middle of its traverse.Figs. 6o and 6i will illustrate the method. Variable… … In Fig. 63 the cam H is used to slide the wheel P out ofgear with the clutch at F.
Textile machinery
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
