A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 130

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 130
6 during the revo-lution of disk 19. and pull it forward. The disk 19 is centered on an eccentric 27 whichhas a handle 2S, and can thus be raised out of con-tact with the worm 23 and set in any desired posi-tion by hand. A bracket 29 on the frame has aguide 30 for an upright headed slide-rod 31… … an arm 35, which is slidably mounted in guides 36on the arm 37 of the bracket 29 and a spring 38inserted between the guides 36 on the arm 35 to keep 130 one end under the collar 32. The opposite end ofarm 35 is bent downward at 26 and, as mentionedbefore, is in the path of movement of the pin 25,so…

Textile fabrics · Textile industry · Textile machinery
