A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 139

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 139
ooden bars being best ex-11 plained by re- ferring to theace ompany-i n g illustra-tion, of whichdiagram A isan end viewof the patternchain barrela s carryingthe patternchain, thebars of whichare shownwith the im-proved c o n-nection, anddiagram B avertical sec-tion througha bar withpattern pegs(in… … 2, said star wheel receiving its motion from a revolv-ing pin (not shown). The pattern chain barrel 1 has at each end a head 3, having grooves 4, to receive the ends of the ironrods 5, of the pattern chain. Two of these rods 5,are connected on either side of the chain by meansof a metal link 6,…

Textile fabrics · Textile industry · Textile machinery
