A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 349

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 349
iption of one will suffice forboth: 47, 48, are inversely-inclined screw threads and49, 50, are other inversely-inclined screw threads.The screw thread 48 is also inversely inclined withrespect to the screw thread 50. and the screw thread 47with respect to the screw thread 49. Screw threads 49and… … the screw threads 47, 48, 49 and 50. The carriages 51and 52, respectively, carry the bearings of the guiderolls 43 and 46. The carriage 53 is pivotally con-nected with one arm of the angle lever 55. 56. whichhas a fixed fulcrum at 57 and carries the roll 45 atthe extremity of its other arm. The…

Textile fabrics · Textile industry · Textile machinery
