, but is stillkept at right angles to the direc-tion of the slant of the strut, whilethe line dc has a pitch var^nng indifferent cases, according to cir-cumstances. 85. A method of footing therafters on tie-beams without the mortise and tenon is shownin Fig. 19 («), where the joint is similar to…
