Fairbairn, William, Sir, 1789-1874 · London, Longman, Green, Longman, Roberts & Green · leaf 116
) and ata (fig. 225), by which it is drawn backwards or forwards as thecase may be. The peculiarity of the clutch (fig. 225) is that of* Extract from Engineer s and Machinists Assistant, p. 144. ox ENGAGIXG .VXD DISENGAGIXG GEAR. 91 the driving shaft, which, reversed by any accident in its… … rijr. 226. Fig. 226 shows one of these clutches on a small scale, fixed ona line of shafting beneath thefloor of a mill. It is placed be-tween two standards eta, sup-porting the ends of the shaft, andthe lever b working on a pivot atbottom, and having a pin work-ing in the groove of the…
Mills and mill-work · Machinery
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
