A treatise on ship-building and navigation. In three parts, wherein the theory, practice, and application of all the necessary instruments are perspicuously handled. With the construction and use of a new invented shipwright's sector ... Also tables of the sun's declination, of meridional parts ... To which is added by way of appendix, an English abridgment of another treatise on naval architecture, lately published at Paris by M. Duhamel .. (1754)

Murray, Mungo, d. 1770, Duhamel du Monceau, M., 1700-1782. Treatise on ship-building · London, Printed for D. Henry and R. Cave, for the author · leaf 224

An illustration from A treatise on ship-building and navigation. In three parts, wherein the theory, practice, and application of all the necessary instruments are perspicuously handled. With the construction and use of a new invented shipwright's sector ... Also tables of the sun's declination, of meridional parts ... To which is added by way of appendix, an English abridgment of another treatise on naval architecture, lately published at Paris by M. Duhamel .., 1754, leaf 224 — ftem. We may now ftation the timbers F, I, M, P, R and S, as inthe plate; for as the touch of the ftem is 6826, and timber P 7430 be-fore 69 ; P will be 604 before the touch of the ftem. We have in theplate laid down the main and top timber half breadth lines, alfo the rif-ing and narrowing of the… … l/affJX./i<-!//f9 B+

Shipbuilding · Navigation

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
