Treatise on the steam engine (1839)

Renwick, James, 1790?-1863 · New-York, Carvill & Co. · leaf 197

An illustration from Treatise on the steam engine, 1839, leaf 197
It is mentionedby Vitruvius, Ltb. I. Cap. VI., as an illustration of the causesof the winds. It was supposed that the blast actually proceed-ed from the Eolipyle, but asjsteam would not support combus-tion, we must look to some other cause for its effects in this res-pect. We find it in the lateral… … It is composed of a globe or other hollow vessel A, to whicha pipe B, is adapted. If a portion of water be introduced, andthe vessel placed over a fire, steam will be generated, and issueforcibly from the narrow aperture. If it be mounted on wheels,it will recoil by the reaction of the escaping…

Steam-engines
