Fig. 270the allis-chalmers steam turbine Alhs-Clialmers Steam Turbine 651 pressure at Y. Valve V is a by-pass valve to allow of livesteam being admitted to the second stage of the cylinderin case of a sudden overload. This by-pass valve is theequivalent of the by-pass valve used to admit live steam… … T ==.| ELEMENTARY PARSONS TYPE STEAM TURBINE Fig. 277 the low pressure cylinder of a compound reciprocating en-gine. Valve V is arranged to be operated, either by thegovernor or by hand, as the conditions may require. Fric-
