Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 390

An illustration from Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery, 1922, leaf 390
Fig. 120 circle. At this point we can stud*y the effect o? inside lap,because if the valve has no inside lap, release on the crankend will begin almost at the same moment that compres-sion takes place at the head end, but by adding inside lap,compression can be caused to take place earlier and… … Fig. 121 The next event is admission at the head end of thecylinder, Fig. 121. The crank has now arrived at 180°,having completed one-half of a revolution; the piston isat the end of the stroke, and the eccentric is at 120° onthe return path. Fig. 122 serves to better illustrate therelative…

Steam engineering · Electrical engineering · Steam-turbines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
