g cover plate and cover angles, which are field-riveted. The columns Q Q Q Q, which support the low ends of CANTILEVER SPANS 357 the anchor spans, and the opposite columns T T T T, whichsupport the low ends of the corresponding 55-ft. approachgirders, are skewed as shown in the plan and elevations,… … character, and are braced in pairs longitudinally, so as tomake towers and single bents. St. Louis, Keokuk &■ Akirt/iwcsteru Bridge. — On the St.Louis, Keokuk & Northwestern Railroad, there are two single-track double cantilever deck plate girder bridges, each loi ft.long over all, and…
