osite to thepiston movement, and its eccentric follows the crank instead of leadingit, as shown in the skeleton diagram of Fig. 94. The balance pistons Bare packed in their bores by spring rings, and have a scraped joint on theback of the valve; this makes a steam-tight passage from steam inlet… … FIG. 99.— VERTICAL SECTION E-F. pin or shaft a. One end of this pin receives the rod from the fixed eccen-tric F, and the other end transmits the motion to the main valve, as shownin Fig. 95. The main valve has thus a fixed travel and governs the ad-mission and release just as in an ordinary slide…
