Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 109

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 109 — v^ … ♦-^ THE BUCKEYE ENGINE 99 105. Lock the eccentric F in place and roll the engine around to the crankcenter; if the work has been accurately done, the valve will show properlead on the crank end. Slight adjustments may be made by the valve stem.This completes the setting of the main valve. If the…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
