Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 141

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 141 — levers of valves 2 and 3far enough to allow the cams whichoperate them to be turned aroundon the shaft, just clearing the leverswithout lifting the valve as shownin Fig. 133. While the levers of 2and 3 are in position, tighten the set screws in the rocker arm E, Fig. 133,at the bottom of the… … FIG. 133. THE PUTNAM ENGINE 131

Steam-engines
