Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 164
of the wrist plate when the crank-end steamvalve is opening and the crank-end exhaust valve is closing is shown bythe arrow on the wrist plate. (At the same time the head-end steam valvehas closed and the exhaust valve is open.) 152 REYNOLDS (1890) AND GIRDER FRAME CORLISS ENGINES 153 The working… … haust valves both indicate lap when the lines on the valves are nearer thecenter of the cylinder than are the lines on the chest. This condition isshown in Fig. 157, which represents the end of one steam valve and chest
Steam-engines
