Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 180

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 180 — n place with a thin wedge driven between the bossof the wrist plate and the cap of the bearing next to it. Then adjust the length of the valve rods so that the plate d in thevalve crank H is horizontal, as in Fig. 169. If there is no adjustmentin the length of the valve rods, then note whether or… … 170 VALVE SETTING proper length, even if they have to be taken to a machine shop for thepurpose. With the gpvernor in its lowest position, adjust the length ofthe rod 8 so that it is at its outer extreme position, as in Fig. 17-i, withthe plate d as shown here and in Figs. 169, 170, 171 and 172.…
