Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 192
n should all be taken up. If the piston does notmake a full stroke, the lost motion may be increased somewhat abovethe figure given, but it must be kept in mind that this will reduce thetravel of the valve and the port opening, and thus may affect the speedof the pump. * Contributed to Power by F.… … FIG. 183. is a connection, provided with a valve, between the two high-pressure ex-haust pipes. The object of this connection is to equalize the pressure in 182 VALVE SETTING these exhaust pipes and make it more uniform. This is called the crossexhaust, and its influence on the distribution of…
Steam-engines
