Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 49
(a) Single valve and cut-off set over the ports in a midposition be-tween the ends of the cylinder; (&) valves bridging ports at each endof the cylinder operating as one; (c) separate valves over each steamvalve port, and separate valves over the steam and exhaust cylinder ports. The cut-off… … FIG. 33. FIG. 34. shorter steam port and independent and closer adjustment of action issecured. It is the purpose of this chapter to treat only of the simplest of Meyercut-off valves, of which Fig. 33 is an illustration. This valve may be soconstructed and connected that it may cut off the steam at…
Steam-engines
