Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 69
osi- tions. A temporary mark should bemade here lightly as at D, Fig. 58. The eccentric should then be turnedto the opposite position and another mark made at C. The distance from5 to C should equal the distance from B to D. If there is any discrepancythe reach rod should be lengthened or shortened… … THE CORLISS STEAM ENGINES 59 the wrist plate in this position and both steam valves hooked on, thevalves should have the proper lap. This may be ascertained by removingthe steam bonnets and inspecting the marks on the valves and seat made J C FIG. 57.— CENTRAL MARKS ONHUB OF WRIST PLATE. 11 n FIG.…
Steam-engines
