Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)
Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 75
or steam valve fromits seat. General Arrangement of Valve Gear The general arrangement of the valve gear, eccentrics, etc., can be seenby reference to Fig. 61, which is the high-pressure side of a cross-com-pound engine. The eccentric shaft A being geared to the main shaft ofthe engines at a makes…
Steam-engines
