ith twosteam valves v, each of which controls one of the f-inch pipecoils already mentioned as being inside the 2-inch coils A, A.From the upper side of the T pieces (, t run the hot-water risersR and R. These risers enter the expansion drum D. Hot-water outflow pipes p and p run from the expansion… … CAR HEATING. § 13 pipes by means of the T pieces t\ t; v, on top of drnni, is thesafety vent to relieve excessive pressures. 47. Action of the Apparatus.—Water is contained inthe coils between the inner and the outer pipes, and is heatedby steam passing from the train pipe P through valve V…
