Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)
American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 132
Q 0 … 6666 Fig. 70. Roller Motion. taking into consideration the shaft from which the power is derived.The pick cam shaft travels half the speed of the crank shaft, so thattwo picks of the pattern are placed in the cloth while the pick camshaft revolves once; thus the gear fixed to the shaft must contain…
Weaving
