Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)

American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 140

An illustration from Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving, 1909, leaf 140
k the cone, giving a jump to the motionwhich often breaks the picking shaft; the pick cam is also some-times loosened by this fault, and such a point requires more powerbehind the motion. When the extreme point is too narrow andreceding, a soft piclv is the result (not an easy pick), lacking the… … -a--H r^—2i—A
