Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)

American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 32

An illustration from Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving, 1909, leaf 32
WARP PREPARATION. 19 or the number of yards in the whole wrap. By the substitutingof the 64 gear below the cut gear the ratio will be equal to 4 to 1.Thus the number of teeth in the gear B will be 4 times greaterthan the number of cuts in the leese. Example. We require 1,000 yards of j^arn on the…
