Wilson’s Carpentry and joinery / by John Wilson (1891)
Wilson, John · Manchester [England] : Percy Bros. · leaf 118
much further this will remove the angle tie from the oorner,keeping both hip and tie level on the underside, as shown at n, Fig. 2. 3. The plans of two hips form a right angle, the surface of the end is45°, and the points measured along the wall plate 12 feet apart, show thetrue shape of the…
Carpentry · Joinery
