Stator Fig. 164. Fig. 165. Fig. 164.—Three-phase induction motor. Squirrel-cage secondary. When running at full speed one lead can be disconnected and the motor will continue to operate single-phase. Fig. 165.—Two-phase induction motor. Squirrel-cage secondary. When running atfull speed one phase… … Fig. 166.—Connections of self-contained auto-starter for three-phase induction motor withsquirrel-cage secondary. Rating: 300 amp. per phase up to 500 volts.
