per on which thedrawing is made to be bent on a line somewhere betweentwo of the views until the surfaces are perpendicular toeach other, or actually bending the paper with the draw-ing on it in this manner, then imagine some object thatif projected on the two planes would give outlines likethe… … 160 WOOD PATTERN MAKING viously mentioned conventions. One of these is thearrangement of the views, which is different from that ofFig. 1 (d). In Fig. 2 (d), the plan, (A) is below thefront view (B), therefore the front view shows the sideof the plan that is the farthest from it. In Fig. 1 this…
