Woodwork for the grades, for use in manual training classes; fully illustrated with three hundred half-tone engravings from actual shop practice, and many working drawings of educational shop problems (1913)
Selden, Frank Henry · Chicago, Orr & Lockett Hardware Co · leaf 26
o work out better methodsof your own, but do not waste your time experimenting or fol-lowing your own notions until you know and have thoroughlytried the methods given in this book. WOODWORK FOR THE GRADES 23 LESSON 4 PLANING FIRST SURFACE Before beginning to plane look carefully at both sides… … Fig. 12—Piece against Stop Place the piece of wood against the bench-stop as shownin Figures 9 and 12 and remove one shaving, taking off theportion indicated by the light colored portion in Fig. 13. Ifthe piece is quite straight and true the shaving may be of thesame width and thickness the entire…
