Woolen and worsted fabrics glossary; containing instructions for the manufacture of every known grade and variety of woolen and worsted fabrics .. (1914)

Bennett, Frank P. and company. [from old catalog] · Boston, New York [etc.] Frank P. Bennett & co., inc · leaf 26

An illustration from Woolen and worsted fabrics glossary; containing instructions for the manufacture of every known grade and variety of woolen and worsted fabrics .., 1914, leaf 26
inches, and remainsthere until sufficient twist has beeninserted. When this has been accom-plished, the fallers assume the properposition, the carriage is drawn in,winding the yarn on the bobbins atthe same time. To one not familiarwith the machine it would seem thatthe roving would be immediately… … End View of Mule.—a, Spool of Roving; a1, Roving Drum; a2, Roving Guide;a3, Sectional Top Roll; a4, a5, Delivery Rolls; a6, Thread; b1, b4, Fall-ers; c7, Spindle; c8, Bobbin; c4, Cylinder. arms, Bl and B4, termed fallers carrywires which serve to keep the yarntaut, and guide it while winding onthe…

Woolen and worsted manufacture
