Perspective and geometrical drawing adapted to the use of candidates for second and third-class teachers' certificates (1887)
McGuirl, Thomas H. (from old catalog) · Toronto, W. Briggs · leaf 56
Fig. 29. We proceed as follows :—After drawing H.L. and B.L. andfinding positions of O, MP and C. Y., take A 4 to right of S;at A erect perpendicular AC = 4, and measure off AE = P andDE = 2. Produce CA to B, making AB = AC and FX = DE;make FG = FX and GH = GA; join HKMP, GLMP, A C. Y., THE… … 52 DRAWING. Draw H.L., B,L., and find O C.V. and MP as before.Make SY and ST each = 1, and make TX and YA each = T;make Ar = 2^, and draw it _)_ to AX; draw XP, TY, YZparallel to AF. Make RG^RL or TY, and GZ also = RL,and complete the oblong MH. Make Aa = AF, Ab = AG andAE = AH; join EMP, hMV, aMP,…
Geometrical drawing · Perspective
